This automatic packaging machine is designed for pyramid tea bags (herbal tea, fruit tea, etc.) and integrates an auto can/bottle filling system. It can form, fill, and seal pyramid tea bags, then transfer them directly into cans, bottles, or containers. Ideal for tea manufacturers looking for a complete solution from bagging to jarring – saving labor and ensuring hygiene.
Key features:
-
Pyramid bag forming (non-woven, mesh, or nylon)
-
Automatic string & tag attachment (optional)
-
Integrated can/bottle filling unit
-
Suitable for herbal, flower, or fruit tea blends
-
Stainless steel construction, easy to clean
Perfect for medium-to-large scale production of premium tea in gift jars or retail cans.
Type: Tea Bag Packing Machine Series
Product model: C28DX
Product name: C28DX Automatic Pyramid/Flat lnner and Outer Bag Packing Machine
Purpose: lt is suitable for inner and outer bag packaging for products such as loose
leaf tea, herbal tea, health care tea,TieGuanYin, LongJing, DaMaoFeng,DaHongPao, rose tea, ginseng, etc.
Feature: The packing material of the triangle bag machine is nylon, non-wovenfabric material imported from Japan, which is non-toxic, no bacteria, heat-resistant high quality food grade material conforming to our nationalsafety inspection standard.The machine uses a unique sealing method -ultrasonic.It can seal tightly, safely, reduce the width of the extra edge,avoiding any waste of packing material.
Packing Material: Nylon material imported from Japan,Non-woven fabric,100%biodegradable transparent material,PET,PLA.
Filling range: 1~10g/bag, accuracy: 0.1g/bag
Filling method: 6 head electronic weigher (8 head weigher can be customized)
Packing roll width: 120mm, 140mm, 160mm, 180mm
Sealing lenght: 50、60、70、80(mm)
Outer bag size: L:90mm-120mm w:80mm-100mm
Sealing method: Sealing and cutting by ultrasonic
Quantity of sealing device: 2sets
Packing speed: 50~65bags/min
Motor power: 220V，50Hz,3KW
Air supply: ≥0.6Mpa(optional with air compressor)
weight: 950KG
Dimension: 2000mm*1200mm*2800mm(L*W*H)
